WOLIZE's Types of Water Supply System
During the production of types of water supply system, Shandong Wolize Biotechnology Co., Ltd. puts such a high value on the quality. We have a complete set of orderly production process, increasing the production efficiency to achieve the production target. We operate under the strict QC system from the initial stage of materials selection to the finished products. After years of development, we have passed the certification of International Organization for Standardization.
WOLIZE products have gained high customer satisfaction and have earned loyalty and respect from old and new customers after years of development. The high-quality products exceed the expectation of lots of customers and really help promote long-term cooperation. Now, the products are well-received in the global market. More and more people are inclining to choose these products, increasing the overall sales.
The product is a modern water supply system designed to deliver clean and reliable water, integrating pipelines, pumps, and storage tanks for efficient distribution. It emphasizes sustainability and adaptability to meet various water demands. Scalable solutions are also provided to fit diverse environmental needs.
How to choose a water system?
- Ensures consistent water pressure and minimal downtime, ideal for areas with fluctuating supply or critical infrastructure needs.
- Suitable for rural regions, high-rise buildings, or locations requiring uninterrupted water access.
- Look for corrosion-resistant materials, redundant pumping systems, and backup storage capacity.
- Optimizes water distribution with minimal energy consumption, reducing operational costs and environmental impact.
- Best for urban households, commercial complexes, or industrial facilities prioritizing resource conservation.
- Check for high flow rates, smart metering integration, and compliance with energy efficiency standards.
- Adaptable designs for diverse applications, including residential, agricultural, or emergency water supply scenarios.
- Ideal for mixed-use developments, modular housing, or regions with varying water quality requirements.
- Select systems with scalable storage, adjustable filtration, and compatibility with municipal or well-water sources.
no data
1. The role of filtering drum machine
The role of filtering drum in recirculating aquaculture systems (RAS) is multifaceted, specifically:
1. Physical filtration to remove suspended matter:
filtering drum can effectively remove suspended solids (TSS) in water, including feed residues, fish feces, dead aquatic organisms, silt, etc., and reduce the organic load in the water. Its filtration accuracy is between 100 microns and 30 microns. For example, the pore size of the common filtering drum machine filter is between 60 and 200 microns. It is like a fine sieve that blocks larger impurities outside the filter and makes the circulating water clearer. In aquaculture, if these suspended solids are not removed in time, they will decompose in the water, consume a lot of oxygen, and produce harmful substances such as ammonia nitrogen, which will affect the growth and health of farmed organisms. Taking the culture of perch as an example, there are more residual bait and feces in the water of perch culture. After using the filtering drum machine, the content of suspended solids in the water can be greatly reduced, which effectively improves the water quality and provides a relatively clean growth environment for perch.
2. Reducing the load on the biofilter
The filtering drum intercepts and removes small particles that cannot be removed by the vertical flow sedimentation device through mechanical filtration, reducing the organic load of the biological filter and providing a more suitable growth environment for nitrifying bacteria. Nitrifying bacteria require a certain amount of organic matter, but too high an organic matter content will cause the reproduction of other microorganisms, competing with nitrifying bacteria for growth space and nutrients. Nitrifying bacteria are very fragile compared to other microorganisms, and a large increase in organic matter in the water body will cause nitrifying bacteria to lose the competition with other microorganisms. Therefore, the filtering drum provides more favorable growth conditions for nitrifying bacteria by removing most of the organic matter, prolonging the service life of the biological filter material and improving the treatment efficiency of the entire system.
3. Improving the effectiveness of ultraviolet disinfection
In a recirculating aquaculture system, filtering drum machines and ultraviolet disinfection equipment usually work together. As a pre-treatment device, the filtering drum machine first removes suspended solids and larger impurities in the water, so that the subsequent ultraviolet disinfection can play a more effective role. The water filtered by the filtering drum machine has increased transparency and reduced suspended matter in the water, so that ultraviolet rays can better penetrate the water body and irradiate the microorganisms in the water, improving the disinfection efficiency. For example, in an actual recirculating aquaculture pond, the sterilization rate of ultraviolet disinfection equipment may only be 70% - 80% for water that has not been filtered by a filtering drum machine due to the large amount of suspended matter. After filtering by a filtering drum machine, the sterilization rate of the same ultraviolet disinfection equipment can be increased to 95% - 99%. At the same time, ultraviolet disinfection can kill tiny pathogens that cannot be removed by filtering drum machines, further purify the water quality, and provide a safer and healthier water environment for aquaculture organisms.
4. Improving water quality and realizing recycling of some water resources
filtering drum machines have a significant effect on reducing suspended solids (SS), chemical oxygen demand (COD) and biochemical oxygen demand (BOD) in water. The reduction of these indicators directly reflects the improvement of water quality and has a good effect on improving the transparency of water bodies. Before using filtering drum machines, circulating water may appear turbid and have low transparency due to the presence of suspended matter. After filtering by filtering drum machines, the transparency of water bodies can be significantly improved. The water filtered by filtering drum machines has significantly improved water quality and can be returned to the breeding pond for recycling. This saves water resources to a certain extent, which is of great economic and environmental significance to recirculating water aquaculture enterprises.
2. Common problems of filtering drum machine
(I) Poor filtering effect
1. Filter blockage
As the filtration process continues, impurities in the water, such as feces and feed residues, will gradually accumulate on the filter. When the filter is severely clogged, the resistance of water flowing through the filter increases, the filtration speed slows down, and some impurities cannot be effectively filtered. For example, in a circulating water system with high-density breeding, if the filter of the filtering drum is not cleaned for a long time, a large amount of organic matter will accumulate on the filter, just like setting a barrier at the entrance of the filter, making it impossible for water to pass smoothly, thereby reducing the filtration effect. At the same time, the clogging of the filter causes the liquid level in the drum cavity of the filtering drum to rise, constantly triggering back washing. The drum motor keeps turning with dozens of tons of water, wasting water and electricity, and accelerating equipment wear. Therefore, filter clogging is the most common and most harmful problem of filtering drum.
2. The filter is damaged:
During long-term use, the filter may be damaged due to the impact of water flow, frequent cleaning or contact with sharp objects. Once the filter is damaged, some larger particles that should have been filtered out will directly pass through the filtering drum machine into the aquaculture water, affecting the water quality.
(II) Backwash system failure
1. Insufficient or excessive backwash intensity
Backwash failures often manifest as insufficient or excessive backwash intensity. The backwash intensity needs to be reasonably adjusted according to the degree and type of filter blockage. If the backwash intensity is insufficient, impurities on the filter cannot be completely removed. This may be caused by a blocked duckbill or a water pump failure. It is recommended to choose a straight high-pressure nozzle instead of a spray nozzle. In addition, the water source for back washing is best connected to tap water or clean water.
If the backwash intensity is too high, the filter structure may be damaged. For example, when setting the backwash parameters, if the viscosity of impurities in the water is not taken into account, the backwash intensity may be inappropriate.
2. Automatic backwash sensor failure
In an automatic backwash system, a fault in the sensor used to detect parameters such as filter blockage degree and water level may cause the backwash to fail to start correctly. For example, the filter blockage degree sensor may not accurately detect the signal that back washing is required due to being covered by impurities, circuit damage, or aging of its own components.
3. Insufficient water pressure or air pressure
filtering drum back washing is often driven by water pressure or air pressure. Insufficient water pressure or air pressure is a common reason why back washing cannot be started. This may be caused by water supply pump or air supply pump failure, pipeline leakage, filter blockage leading to reduced water or air supply, etc.
(III) Motor failure
1. Overload
If the filter screen of the filtering drum is seriously clogged, the load of the motor will suddenly increase, requiring the motor to have a greater torque to drive the drum, thus causing overload. Long-term overload operation will cause the motor to overheat or even burn out.
2. Short circuit:
In a humid breeding environment, if the motor protection measures are not in place, water may enter the motor and cause the motor to short-circuit. Motor short-circuit can cause tripping, and in severe cases may damage key components such as the motor windings. For example, when the filtering drum machine's housing is not well sealed or the motor's waterproof level is not enough, water splashes into the motor during heavy rain or when cleaning the equipment, which can easily cause a short circuit.
The role of filtering drum in recirculating aquaculture systems (RAS) is multifaceted, specifically:
1. Physical filtration to remove suspended matter:
filtering drum can effectively remove suspended solids (TSS) in water, including feed residues, fish feces, dead aquatic organisms, silt, etc., and reduce the organic load in the water. Its filtration accuracy is between 100 microns and 30 microns. For example, the pore size of the common filtering drum machine filter is between 60 and 200 microns. It is like a fine sieve that blocks larger impurities outside the filter and makes the circulating water clearer. In aquaculture, if these suspended solids are not removed in time, they will decompose in the water, consume a lot of oxygen, and produce harmful substances such as ammonia nitrogen, which will affect the growth and health of farmed organisms. Taking the culture of perch as an example, there are more residual bait and feces in the water of perch culture. After using the filtering drum machine, the content of suspended solids in the water can be greatly reduced, which effectively improves the water quality and provides a relatively clean growth environment for perch.
2. Reducing the load on the biofilter
The filtering drum intercepts and removes small particles that cannot be removed by the vertical flow sedimentation device through mechanical filtration, reducing the organic load of the biological filter and providing a more suitable growth environment for nitrifying bacteria. Nitrifying bacteria require a certain amount of organic matter, but too high an organic matter content will cause the reproduction of other microorganisms, competing with nitrifying bacteria for growth space and nutrients. Nitrifying bacteria are very fragile compared to other microorganisms, and a large increase in organic matter in the water body will cause nitrifying bacteria to lose the competition with other microorganisms. Therefore, the filtering drum provides more favorable growth conditions for nitrifying bacteria by removing most of the organic matter, prolonging the service life of the biological filter material and improving the treatment efficiency of the entire system.
3. Improving the effectiveness of ultraviolet disinfection
In a recirculating aquaculture system, filtering drum machines and ultraviolet disinfection equipment usually work together. As a pre-treatment device, the filtering drum machine first removes suspended solids and larger impurities in the water, so that the subsequent ultraviolet disinfection can play a more effective role. The water filtered by the filtering drum machine has increased transparency and reduced suspended matter in the water, so that ultraviolet rays can better penetrate the water body and irradiate the microorganisms in the water, improving the disinfection efficiency. For example, in an actual recirculating aquaculture pond, the sterilization rate of ultraviolet disinfection equipment may only be 70% - 80% for water that has not been filtered by a filtering drum machine due to the large amount of suspended matter. After filtering by a filtering drum machine, the sterilization rate of the same ultraviolet disinfection equipment can be increased to 95% - 99%. At the same time, ultraviolet disinfection can kill tiny pathogens that cannot be removed by filtering drum machines, further purify the water quality, and provide a safer and healthier water environment for aquaculture organisms.
4. Improving water quality and realizing recycling of some water resources
filtering drum machines have a significant effect on reducing suspended solids (SS), chemical oxygen demand (COD) and biochemical oxygen demand (BOD) in water. The reduction of these indicators directly reflects the improvement of water quality and has a good effect on improving the transparency of water bodies. Before using filtering drum machines, circulating water may appear turbid and have low transparency due to the presence of suspended matter. After filtering by filtering drum machines, the transparency of water bodies can be significantly improved. The water filtered by filtering drum machines has significantly improved water quality and can be returned to the breeding pond for recycling. This saves water resources to a certain extent, which is of great economic and environmental significance to recirculating water aquaculture enterprises.
2. Common problems of filtering drum machine
(I) Poor filtering effect
1. Filter blockage
As the filtration process continues, impurities in the water, such as feces and feed residues, will gradually accumulate on the filter. When the filter is severely clogged, the resistance of water flowing through the filter increases, the filtration speed slows down, and some impurities cannot be effectively filtered. For example, in a circulating water system with high-density breeding, if the filter of the filtering drum is not cleaned for a long time, a large amount of organic matter will accumulate on the filter, just like setting a barrier at the entrance of the filter, making it impossible for water to pass smoothly, thereby reducing the filtration effect. At the same time, the clogging of the filter causes the liquid level in the drum cavity of the filtering drum to rise, constantly triggering back washing. The drum motor keeps turning with dozens of tons of water, wasting water and electricity, and accelerating equipment wear. Therefore, filter clogging is the most common and most harmful problem of filtering drum.
2. The filter is damaged:
During long-term use, the filter may be damaged due to the impact of water flow, frequent cleaning or contact with sharp objects. Once the filter is damaged, some larger particles that should have been filtered out will directly pass through the filtering drum machine into the aquaculture water, affecting the water quality.
(II) Backwash system failure
1. Insufficient or excessive backwash intensity
Backwash failures often manifest as insufficient or excessive backwash intensity. The backwash intensity needs to be reasonably adjusted according to the degree and type of filter blockage. If the backwash intensity is insufficient, impurities on the filter cannot be completely removed. This may be caused by a blocked duckbill or a water pump failure. It is recommended to choose a straight high-pressure nozzle instead of a spray nozzle. In addition, the water source for back washing is best connected to tap water or clean water.
If the backwash intensity is too high, the filter structure may be damaged. For example, when setting the backwash parameters, if the viscosity of impurities in the water is not taken into account, the backwash intensity may be inappropriate.
2. Automatic backwash sensor failure
In an automatic backwash system, a fault in the sensor used to detect parameters such as filter blockage degree and water level may cause the backwash to fail to start correctly. For example, the filter blockage degree sensor may not accurately detect the signal that back washing is required due to being covered by impurities, circuit damage, or aging of its own components.
3. Insufficient water pressure or air pressure
filtering drum back washing is often driven by water pressure or air pressure. Insufficient water pressure or air pressure is a common reason why back washing cannot be started. This may be caused by water supply pump or air supply pump failure, pipeline leakage, filter blockage leading to reduced water or air supply, etc.
(III) Motor failure
1. Overload
If the filter screen of the filtering drum is seriously clogged, the load of the motor will suddenly increase, requiring the motor to have a greater torque to drive the drum, thus causing overload. Long-term overload operation will cause the motor to overheat or even burn out.
2. Short circuit:
In a humid breeding environment, if the motor protection measures are not in place, water may enter the motor and cause the motor to short-circuit. Motor short-circuit can cause tripping, and in severe cases may damage key components such as the motor windings. For example, when the filtering drum machine's housing is not well sealed or the motor's waterproof level is not enough, water splashes into the motor during heavy rain or when cleaning the equipment, which can easily cause a short circuit.
The recirculating aquaculture system is a new type of aquaculture model, which uses a series of water treatment
units to process the wastewater generated in the aquaculture pond and then recycle it. The main principle of
RAS is to integrate advanced technologies in environmental engineering, civil engineering, modern biology,
electronic information and other disciplines to remove residual bait feces, ammonia nitrogen (TAN), nitrite nitrogen
(NO2--N ) and other harmful pollutants. For the purpose of purifying the breeding environment, the process of re-entering the purified water into the breeding pond by using physical filtration, biological filtration, removal of CO2,
disinfection, oxygenation, temperature adjustment and other treatments. It can not only solve the problem of low
utilization rate of water resources, but also provide a stable, reliable, comfortable and high-quality living environment
for breeding organisms, and provide favorable conditions for high-density farming.
