Overall Layout and Planning Process
The layout and planning of a land-based industrial recirculating aquaculture workshop are divided into two phases: the Planning Phase and the Design Phase.
1.Planning Phase
Step 1: Determine Aquaculture Species
The first step is to select the aquaculture species and conduct a feasibility analysis to determine the return on investment (ROI). Different species require varying scales of investment and equipment specifications. Failure to define the species will hinder decisions on capital allocation and equipment selection.
Step 2: Determine Investment Scale
Based on the selected species, combined with available capital and land resources, develop an overall blueprint for the facility. Determine the number of construction phases and the scale of each phase.
Step 3: Determine Production Output and Stocking Density
The final step in the planning phase is to define the production output and stocking density for the first phase. These parameters are essential for calculating the required aquaculture area and designing the workshop layout.


2.Design Phase
In the design phase, the size of the aquaculture area should be determined based on the aquaculture yield and density determined in the first phase, and the model and parameters of the equipment should be determined.
Layout of land-based factory based circular aquaculture workshop
1. Functional zoning
1) Breeding area
The breeding area is the core of the workshop, and the breeding pools are arranged in an orderly manner, which can be flexibly set according to the breeding varieties and scale. The shapes of aquaculture ponds are diverse, such as circular ponds with uniform water flow, which are conducive to collecting pollutants; The square rounded pool has a high utilization rate of space. The layout of the breeding area should ensure that staff can easily carry out feeding, inspection, fishing and other operations, and appropriate passages should be reserved between pools.
2) Circulating water treatment area
Various water treatment equipment, such as microscreen drum filters, biochemical filters, ultraviolet sterilizers, etc., are centrally placed in the circulating water treatment area. This area needs to be close to the aquaculture zone to shorten the pipeline length, reduce water flow resistance and energy loss. The water treatment equipment is arranged in sequence according to the process flow to ensure that the effluent from aquaculture reaches the standard of recycling after being treated layer by layer.
3) Supporting facilities area
The supporting facilities area includes distribution rooms, control rooms, feed storage rooms, drug storage rooms, etc. The distribution room should ensure stable power supply, while the control room is used for centralized monitoring of various parameters of the aquaculture system, such as water temperature, water quality, dissolved oxygen, etc., in order to adjust the aquaculture environment in a timely manner. The feed storage room should be kept dry and ventilated to prevent the feed from getting damp and moldy; The drug storage room must comply with relevant safety regulations, classify and store drugs for easy access.
2. Logistics and Water Flow
1) Logistics
Plan clear material transportation channels from the workshop entrance to the breeding area, supporting facilities area, etc., to ensure smooth transportation of feed, fish fry, equipment and other materials. The width of the channel should meet the requirements for transportation vehicles or handling tools to avoid congestion.
2) Water flow
Design a reasonable water flow path. After the aquaculture wastewater is discharged from the aquaculture pond, it is sequentially filtered by a microscreen drum filter to remove large solid waste particles, and then enters a biochemical filter for biological treatment to degrade harmful substances such as ammonia nitrogen. It is then disinfected by a UV sterilizer and finally transported back to the aquaculture pond through equipment such as a water pump, forming a closed circulation system. The direction of water flow should avoid detours and intersections as much as possible to reduce head loss.
3.Key Design Points for Land-Based RAS Workshop
（1） Key points of aquaculture area design
1. Design of aquaculture ponds
1) Shape and Size
Circular aquaculture ponds generally have a diameter of 6-8 meters, a depth of 1.5-2 meters, and a conical bottom for easy collection and discharge of pollutants. The square rounded pool edge is 6-8 meters long, with a side height of 1.2-1.5 meters. The bottom corner is designed with rounded corners to reduce dead corners in water flow. The size of the aquaculture pond should be determined based on the growth habits and breeding density of the aquaculture species to ensure sufficient activity space and growth environment for fish.
2) Material selection
Common types include galvanized corrugated steel with canvas pool, PP material pool, brick mixed water mud pool, etc. Galvanized corrugated steel with canvas pool construction is convenient, cost-effective, and has certain flexibility and durability; PP material pool is corrosion-resistant, easy to clean, and has a long service life; The brick mixed water mud pool is sturdy and durable, with good insulation performance, but the construction period is long and the cost is high. Suitable materials can be selected based on actual needs and economic conditions.
2. Vertical flow sedimentation device
The vertical flow sedimentation device plays an important role in the land-based factory based recirculating aquaculture workshop. From the perspective of solid waste treatment process, it is a key link in the initial purification of water quality. During the aquaculture process, large particles of impurities such as residual bait and feces produced by fish will enter the vertical flow sedimentation device with the water flow. Due to its special vertical flow design, the flow velocity gradually slows down during the upward process, causing heavier solid particles to gradually settle to the bottom under the action of gravity, achieving preliminary solid-liquid separation. Sedimentable particles with a particle size greater than 100 microns can be removed through a vertical flow settler. According to statistics, vertical flow sedimentation can handle 80% of solid particles. This effective interception can prevent them from entering more refined water treatment equipment, reduce the risk of equipment blockage, and extend the service life of the equipment.
3. Breeding density and layout of breeding ponds
1) Breeding density
Determine a reasonable breeding density based on factors such as breeding species, pond size, and water treatment capacity. Excessive breeding density can lead to water quality deterioration, disease growth, and other issues, while excessively low density can affect breeding efficiency. For example, sea bass is cultured in a circular pool with a diameter of 6 meters and a depth of 1.5 meters, and the breeding density can be controlled at around 50kg per cubic meter of water.
2) Layout of aquaculture ponds
Aquaculture ponds can be arranged in rows or columns, with sufficient space left between rows and columns to facilitate personnel operation and equipment maintenance. The general spacing between rows is 1.2 meters, and the spacing between columns is 2 meters. The vertical flow sedimentation device is placed between two breeding ponds.
（2） Key points of design for circulating water treatment area
1. Solid particulate matter treatment area
The removal of solid particulate matter is an important step in the water treatment of recirculating aquaculture systems, and is usually the first step in water treatment. The core method for removing solid particles in recirculating aquaculture is physical filtration. Through mechanical filtration, gravity separation, and other methods, suspended particles, feed residues, fish manure, and other solid substances in water are intercepted and removed to purify water quality. According to the size of solid particles, the process of removing solid particles includes three steps: pretreatment, coarse filtration, and fine filtration. The vertical flow settler is the first pre-treatment process and needs to be installed next to the breeding pool in the breeding area. The microfiltration machine for coarse filtration and the protein separator for fine filtration need to be installed in the circulating water treatment area.



2. Microfiltration machine
Select a microscreen drum filter with appropriate treatment capacity based on the scale of aquaculture and wastewater discharge. The filter aperture of a microscreen drum filter is generally 200 mesh. The specifications of the microscreen drum filter should be selected based on the circulation capacity of the system design. The larger the circulation volume, the larger the specifications of the microscreen drum filter. Generally, for 500 cubic meters of aquaculture water, a microfiltration machine with a water capacity of 300-500 tons per hour should be selected. The microscreen drum filter should be installed near the drainage outlet of the aquaculture area to minimize the residence time of wastewater in the pipeline and avoid solid waste settling and blocking the pipeline. Ensure the levelness of the microscreen drum filter during installation to facilitate normal operation and maintenance of the equipment.
3. Pump pool
The circulating water aquaculture pump pool is the core component of the circulating water aquaculture system, responsible for the circulation, filtration, and transportation of water bodies. The rationality of pump pool design directly affects the operational efficiency and water quality stability of the aquaculture system.
1) The function of the pump pool
Provide power support
The pump pool, as the "heart" of the entire circulating water system, is equipped with a water pump that is responsible for extracting treated water from the sedimentation tank or other treatment processes and transporting it to the aquaculture tank. By operating the water pump, sufficient kinetic energy is given to the water body, overcoming pipeline resistance and water level differences, ensuring that the water flow can circulate continuously and stably between various areas, and maintaining the normal operation of the aquaculture system. Without the power provided by the pump pool, the entire circulating water process will come to a standstill, and the living environment for fish will rapidly deteriorate.
Buffer and voltage stabilization
It can buffer pressure changes caused by pump start stop or water flow fluctuations, avoiding impact damage to pipelines and equipment. When the water pump suddenly starts, a large amount of water is quickly sucked into the pump pool. At this time, the larger volume of the pump pool can accommodate the instantaneous influx of water flow, ensuring a smooth transition in flow velocity and preventing excessive water pressure from impacting subsequent pipelines; Similarly, when the water pump stops running, the remaining water in the pump pool can be slowly released to maintain a certain water pressure in the system, ensuring that some equipment (such as the microbial community in the biochemical filter) is still in a relatively stable working environment and guaranteeing the sustainability of water treatment effectiveness.
2) Key points of pump pool design
Volume determination
The capacity of the pump pool needs to take into account factors such as aquaculture scale, pump flow rate, and system operation stability. Generally speaking, the volume of the pump pool should account for 8% -9% of the entire aquaculture water body. Ensure that there is sufficient buffer water in the pool during the start and stop of the water pump to prevent emptying or overflow.
Internal structure optimization
A guide plate can be installed inside the pump pool to guide the water flow smoothly into the suction port of the water pump and improve the efficiency of the water pump; A liquid level gauge can also be added to monitor the water level in the pool in real time, and linked with the water pump control system to achieve automatic start stop, further optimizing operation management and improving the performance of the entire circulating water aquaculture system. The pump pool should have an overflow design. When the water temperature is too high, it can be drained through an overflow pipe to prevent water from overflowing the pump pool.
Location of pump pool
The pump pool is located below the microscreen drum filter, at the lowest position of the entire circulating water system. The water flows directly into the pump pool after being filtered by a microscreen drum filter.
4. Design points of protein separator
Protein separators are mainly used to remove small suspended particles below 30 μ m and some soluble organic matter, while also having certain functions of oxygenation and decarbonization gas. The protein separator is located behind the pump tank, and the water from the pump tank enters the biofilter after passing through the protein separator
（3） Design points of biological filter
The biofilter in the recirculating aquaculture system is one of the core components of water treatment. Its main function is to degrade harmful substances such as ammonia nitrogen and nitrite in water through the action of microorganisms, and maintain water quality stability. The volume of the biological filter and the amount of biological packing directly affect its treatment efficiency, operational stability, and overall performance of the aquaculture system.
1. Volume of biological filter
The volume of the biofilter in the recirculating aquaculture system should be determined according to different aquaculture species. For example, the low biological carrying capacity of South American white shrimp results in a lower feeding amount in cubic water bodies. Therefore, the proportion of the volume of the biological filter to the total aquaculture water is relatively low. The volume of biological filter tank for breeding carnivorous fish such as Siniperca chuatsi and Perch is 10% -20% larger than that for herbivorous fish such as grass carp and crucian carp due to the large amount of nitrogen containing waste discharged, so as to strengthen the water purification capacity and meet their demand for high-quality water quality. Taking sea bass as an example, the volume of the biological filter should account for 50% of the entire aquaculture water.
2. Multi stage filtration and hydraulic retention time
The longer the hydraulic retention time in the biological filter, the better the removal effect of ammonia nitrogen sub salts. The hydraulic retention time is determined by the volume of the biofilter and the number of stages of multi-stage filtration. The larger the volume of the biological filter, the more layers it filters, and the longer the hydraulic retention time. Therefore, when designing biofilters, it is advisable to achieve multi-stage filtration as much as possible
3. Quantity of biological fillers
The core of a biological filter is the biological filter material, and the quantity of biological filter material determines the nitrification capacity. The filling ratio of biological filter material should ideally reach 40% -50% of the biological pool.
4. Aeration system
Oxygen can be the limiting factor for nitrification rate in biofilters, as its content in the water is low and it is subject to competition from heterotrophic bacteria. 4.57g of oxygen is required for every 1g of ammonia nitrogen to be oxidized into nitrate nitrogen. The growth rate of nitrifying bacteria decreases when the dissolved oxygen is below 4mg/L. Therefore, the biological filter must maintain sufficient dissolved oxygen to ensure the operation of the nitrification system.
An aeration disc with a diameter of 215mm and a gas flow rate of 2m3/h is installed at the bottom of the biological filter. Two Roots blowers with a power of 5.5-7.5kw (or high-speed centrifugal fans) and a gas flow rate of 4.5m3/min are equipped to aerate the biological filter and allow the biological packing to fully roll.
4） Key points of disinfection and sterilization design
1. Selection and installation of ultraviolet sterilizers
Select a UV sterilizer with appropriate power and diameter according to the requirements of circulating water flow rate and water quality. The ultraviolet sterilizer should be installed on the circulating water pipeline, near the inlet of the breeding pool, to ensure that the treated water is fully disinfected before entering the breeding pool. During installation, attention should be paid to avoiding pipeline leakage and ultraviolet radiation leakage to ensure the safe operation of the equipment.

2. Other disinfection methods
In addition to ultraviolet sterilization, ozone disinfection, chlorine disinfection and other methods can also be used according to the actual situation. Ozone disinfection has the advantages of good sterilization effect and no residue, but it requires specialized ozone generators and exhaust gas treatment devices; Chlorine based disinfection has a lower cost, but improper use may cause toxicity to fish, and strict control of dosage and residual chlorine concentration is required.
（5） Design points of oxygenation system
1. Gas source
The dissolved oxygen in recirculating aquaculture is crucial, as the level of dissolved oxygen determines the density of aquaculture. From the perspective of system composition, the oxygenation system mainly includes the gas supply part, gas transportation, aeration device, and supporting control system. The gas supply can come from air compressors, oxygen concentrators, or liquid oxygen tanks. Liquid oxygen tanks can provide a large amount of high concentration oxygen in a short period of time and are commonly used in large-scale industrial aquaculture to ensure sufficient dissolved oxygen in the aquaculture water under high-density aquaculture loads. When designing a circulating water workshop, if there is a liquid oxygen gas source, it is recommended to choose liquid oxygen as the first choice. So it is necessary to leave space outdoors for installing liquid oxygen tank and design corresponding air supply pipelines. If there is no liquid oxygen, an oxygen generator can be installed as the oxygen source. This requires leaving space for the oxygen generator in the water treatment area
2. Oxygen cone
Oxygen cone is an efficient oxygenation device in recirculating aquaculture systems. Its unique design and working principle make it perform well in high-density aquaculture and environments that require high dissolved oxygen. The oxygen cone can achieve an oxygen dissolution efficiency of over 90% by thoroughly mixing pure oxygen with water, which is much higher than traditional oxygenation equipment. At the same time, oxygen cones can significantly increase the dissolved oxygen concentration in water in a short period of time, making them suitable for high-density aquaculture or emergency oxygenation needs. Oxygen cones are usually vertical conical structures with a small footprint, which can improve land use efficiency. When designing a circular aquaculture workshop, it is necessary to reserve a certain area for the oxygen cone, which can be placed in the open space between large equipment in a timely manner.
3. Nano aeration disc
Nano ceramic disc oxygenation is an advanced oxygenation technology in recirculating aquaculture systems, which utilizes aeration discs made of nano ceramic materials to efficiently dissolve oxygen into the water. Compared to traditional oxygenation methods, nano ceramic discs have significant advantages in oxygenation. Firstly, the surface of the nano ceramic disk has a uniform microporous structure, which can generate extremely small bubbles (usually less than 1 millimeter in diameter), greatly increasing the contact area between oxygen and water. Due to the small size and slow rising speed of bubbles, the residence time of oxygen in water is prolonged, and the dissolution efficiency is significantly improved, usually reaching 35% -40%.
When designing nano ceramic disks, they can be configured according to the size of the water body. Generally, a nano ceramic disk is designed with 10-15 cubic meters of water. When installing nanoceramic discs, they can be evenly placed at the bottom of the breeding pond.

（6） Key points of supporting facility area design
1. Distribution room design
1) Load calculation
Calculate the total power load based on the total power of all electrical equipment in the breeding workshop, and reserve a certain margin to meet the potential increase in equipment power demand in the future. At the same time, the stability and reliability of power supply should be considered, and dual power sources or backup generators can be equipped to ensure that the aquaculture system can operate normally for a period of time in the event of a power outage.
2) Layout of power distribution equipment
Reasonable layout of distribution cabinets, transformers, cable trays and other distribution equipment should be arranged inside the distribution room. The distribution cabinet should be installed in a dry and well ventilated location for easy operation and maintenance. Cable trays should be laid according to specifications, with strong and weak electricity separated to avoid electromagnetic interference. The floor of the distribution room should be covered with insulated flooring, and the walls and ceiling should be treated with fire protection to ensure electrical safety.
2. Control room design
1) Monitoring system configuration
The control room is the "brain" of the entire breeding workshop and should be equipped with advanced monitoring systems, including water quality monitors, water temperature sensors, dissolved oxygen meters, video surveillance equipment, etc. The water quality monitor should be able to monitor key indicators such as ammonia nitrogen, nitrite, nitrate, pH value, etc. in the water in real time; The water temperature sensor and dissolved oxygen meter should accurately measure the temperature and dissolved oxygen content of the aquaculture water; Video surveillance equipment should cover important areas such as breeding areas and water treatment areas to facilitate real-time observation of breeding conditions and equipment operation status by staff.
2) Control system design
Establish an automated control system to achieve remote control and automatic adjustment of various equipment in the breeding workshop. For example, automatically adjusting the operating power of the fan or oxygen generator based on the dissolved oxygen content of the aquaculture water; Automatically turn on or off the heating device according to changes in water temperature; Automatically control the operation time and dosage of water treatment equipment based on water quality indicators. The control system should have data storage and analysis functions, be able to record various parameter changes during the breeding process, and provide data support and decision-making basis for breeding management.
3. Design points for feed storage room and drug storage room
1) Feed storage room
The feed storage room should be kept dry, ventilated, and cool. The floor should be treated with moisture-proof measures, such as laying moisture-proof mats or using moisture-proof materials. Feed should be stored by category, and different varieties and specifications of feed should be stacked separately and clearly labeled. Temperature and humidity meters should be equipped in the storage room to regularly monitor the environmental temperature and humidity, ensuring that the quality of feed is not affected. The stacking height of feed should be moderate to avoid excessive pressure and spoilage of the bottom feed.
2) Drug storage room
The drug storage room should comply with relevant safety regulations, set up dedicated drug cabinets or shelves, and store drugs by category. Disinfectants, insecticides, antibiotics, etc. should be stored separately and clearly labeled with drug names, specifications, expiration dates, and other information. The drug storage room should be equipped with ventilation equipment, fire-fighting equipment, etc. to ensure environmental safety. At the same time, a drug inventory registration system should be established to record in detail the procurement, use, and inventory of drugs for easy management and traceability.

（7） Design points of ventilation and temperature control system
1. Ventilation system
1) Ventilation method selection
According to the scale and structure of the breeding workshop, a combination of natural ventilation and mechanical ventilation can be used. Natural ventilation is mainly achieved through skylights on the top of the workshop and ventilation windows on the side walls. When weather conditions permit, natural wind should be used as much as possible for ventilation and air exchange. Mechanical ventilation involves installing exhaust fans, axial fans, and other equipment to force air flow, expel polluted air from the workshop, and introduce fresh air.

2) Ventilation Calculation and Equipment Selection
Calculate the required ventilation based on factors such as breeding density, water evaporation, and equipment heat dissipation in the breeding workshop. Generally speaking, the ventilation required per kilogram of fish per hour is 0.1-0.3 cubic meters. Based on the calculated ventilation volume, select ventilation equipment with appropriate power and air volume, and arrange ventilation openings and ducts reasonably to ensure uniform air circulation and no dead corners in the workshop.
2. Temperature control system
For varieties that require winter heating for breeding, suitable heating equipment such as boilers, heat pumps, electric heaters, etc. should be selected. The boiler has high heating efficiency, but requires specialized boiler rooms and chimneys, resulting in high operating costs; Heat pumps have good energy-saving effects, but require a large initial investment; Electric heaters are easy to install, but their operating costs are also relatively high. Select heating equipment based on factors such as breeding scale, energy supply conditions, and economic costs. The installation position of heating equipment should be reasonable to ensure that hot water can be evenly delivered to each breeding pool. Heating efficiency and energy utilization can be improved by installing hot water circulation pumps and pipeline insulation measures.
（8） Design of Circulating Water Pipeline System
The circulating water pipeline system should include the inflow, outflow, drainage, oxygenation, and replenishment of the aquaculture pond. The "blood vessels" of high-density circulating aquaculture systems through pipelines. If the pipeline layout is improper or the design is incorrect, it will expose aquaculture products to multiple risks. The pipeline layout needs to fully consider factors such as the location, size, quantity of aquaculture ponds, and the location of water treatment areas. Through scientific and rational layout planning, it is possible to ensure that aquaculture water can be evenly and quickly transported to various aquaculture ponds, while also facilitating the timely transportation of waste and water with abnormal water quality back to the treatment area for treatment. The circulating water pipeline system should be installed in the pipeline ditch, and sufficient maintenance and operation space should be left for each layer of pipeline. Labels can be affixed to pipelines and other areas that require identification, with identification symbols consisting of characteristic names, flow directions, and main process parameters.
1. Composition of pipeline system:
1) Inlet pipeline
The inlet pipe is responsible for sending the treated water back to the breeding pond. The inlet main pipe usually uses PP or PVC pipes with a diameter of 200mm to 315mm, and the inlet pipe diameter is 75mm to 110mm, controlled by valves to control the inlet flow rate.
2) Return water pipeline
The return water pipeline is responsible for sending the water from the breeding pond back to the treatment system. The return water pipeline is usually set in the pipeline trench, and PVC water supply pipes with a diameter of 160mm to 400mm are commonly used.
3) Drainage pipeline
Used for emptying water from aquaculture ponds, discharging pollutants from vertical flow sedimentation devices, and backwashing pollutants from microfiltrations. PVC pipes with a diameter of 200mm to 250mm are commonly used for drainage pipelines. One end is connected to an outdoor sedimentation tank, and the other end is equipped with a high-pressure water pump for regular flushing of accumulated dirt in the pipeline.
4) Oxygenation pipeline
Used to provide oxygen to the breeding pool. The oxygenation pipeline system is divided into two parts: one is to place nano ceramic oxygenation disks in the breeding pool, and connect the gas flow meter regulating system outside the pool through high-pressure PU pipes; The second method is to mix oxygen and water thoroughly through a pure oxygen mixer, and then enter the breeding pool through a separate PVC pipeline.
5) Water replenishment pipeline
The water replenishment pipeline should be connected to the storage tank of the circulating water system. Water replenishment pipelines are usually made of corrosion-resistant materials such as PVC or PP pipes to ensure long-term stable operation of the pipeline. Pipes with diameters ranging from 32mm to 75mm are commonly used. Electric regulating valves and water level sensors can be installed on the water replenishment pipeline to monitor the water level of the breeding pool or storage tank in real time through the water level sensor. When the water level is lower than the set value, the electric regulating valve automatically opens to replenish water; When the water level reaches the set value, the electric regulating valve automatically closes.
2. Principles of pipeline layout
1) Reduce resistance
The pipeline layout should minimize the number of bends and joints to reduce head loss and ensure smooth water flow.
2) Reasonable direction
Pipelines should be placed in dedicated pipeline trenches as much as possible to protect them from external environmental influences. The direction of the pipeline should be as simple and reasonable as possible, avoiding crossing.
3) Easy to maintain
Each layer of pipeline should leave sufficient space for maintenance and operation, facilitating daily maintenance and repair.
In order to ensure the stable operation of the system in case of emergencies, pipeline design also needs to consider emergency measures. For example, in emergency situations such as power outages, equipment such as backup generators and emergency oxygenation devices can be used to ensure that the aquaculture water can continue to circulate and avoid deterioration of water quality that could harm the aquaculture organisms.
3. Pipeline layout diagram
Pipeline design is crucial, and specialized pipeline design drawings need to be drawn.

(9) How to optimize workshop design to reduce heating energy consumption
1. In terms of structural design
1) Material selection for walls and roofs
Use building materials with good thermal insulation performance, such as polyurethane foam, rock wool, etc., to build walls and roofs of workshops. For the roof, a triangular apex or arch structure can be used, and covered with materials such as asbestos tiles and fiberglass tiles.
2) Set up insulation layer
Install insulation layers inside the walls, floors, and roofs of the workshop to reduce heat loss. The thickness of the insulation layer should be determined according to the local climate conditions and insulation requirements
3) Sealing design
Ensure good sealing of doors, windows, ventilation openings, and other parts of the workshop to prevent cold air from entering and heat loss. Sealing strips can be installed or sealant can be used for sealing treatment
2. Equipment selection and layout
1) Choose efficient and energy-saving heating equipment
The use of efficient and energy-saving heating equipment such as heat pumps can effectively reduce energy consumption and operating costs. Heat pumps can heat aquaculture water by absorbing heat from the environment, and have a high energy efficiency ratio.
2) Use insulation fabric or insulation film
Setting up insulation curtains or films in the workshop can further prevent heat loss. For example, installing a rolling shutter and insulation curtain on the top of a transparent shed.
Through the comprehensive application of the above measures, the insulation effect of the circular water aquaculture workshop can be effectively improved, energy consumption and production costs can be reduced, and the aquaculture efficiency can be improved.

The impact of fish pond excrement on fish: Because aquaculture fish have always stayed in the water, the impact of changes in water quality on aquaculture products is still relatively large. Excessive accumulation of excrement in fish ponds will lead to excessive ammonia nitrogen content in water, which will cause infection, poisoning, hypoxia and even death of farmed fish. Because fish breathe through the cheeks, ammonia nitrogen in water will penetrate into the fish body through the cheeks, which will reduce fish eating, slow growth, reduce feed conversion rate, reduce oxygen transport between fish tissues, lose balance in water and even die.

So what should be done about the effluent of wolize's canvas fish pond? The materials needed to prepare for the sewage of the canvas pond are roughly matching fish toilets, a number of sewage drainage pipes (PVC water pipes and air pipes), and the entire drainage and sewage system has water sources, inlet and outlet, various channels, sluice gates, catchment pools, and so on. In order to facilitate sewage discharge, the bottom of the fish pond is generally recommended to make the bottom of the pot shape, so that some of the waste and slag of the flowing fish pond through the water body will converge to the center of the fish pond, in this position to install the fish toilet, the fish pond excrement can be smoothly discharged through the fish toilet and pipe, to keep the water quality clean.

The sewage design of the canvas fish pond is relatively simple, because the canvas fish pond is a regular shape, there is no cleaning dead corners, there will be no silt blockage, and the installation location of the fish toilet and pipeline can be determined according to the site selection and personal needs of the fish pond, and the limitation is relatively small. In addition to fish toilet sewage, conditions can also be made into fish and vegetables symbiotic circulating water filtration system, fish and vegetables double harvest saving resources is more ecological and environmental protection.
